Aventon Pace 500.3

Aventon Pace 500.3

$1,799.00
$1,799.00
Sale Sold out
Color
Size
Frame

Free Extra Battery With Purchase

Save $500 with the purchase of this E-Bike as a spare battery is included automatically!

Aventon Battery

Technical Specifications

General Info

  • Model: Aventon Pace 500.3 Step-Through Ebike
  • Ideal Use: Cruising
  • Folding: No
  • Rider Height: 4'11" - 6'1"
  • Dimensions: Bike Box 150cm x 27cm x 86cm

Performance

  • Speed: 28 MPH
  • Pedal Assist: 4 Levels
  • Range: Up to 60 miles
  • Weight: 52 lbs
  • Total Weight Limit: 300 lbs

Frameset

  • Frame Style: Step-Through
  • Frame: Single-Butted Aluminum Alloy
  • Fork: AE-E08 PACE V2 AL fork

Wheelset

  • Rim: Double Wall Aluminum 36h Front & Rear
  • Tubes: Butyl Rubber, Schrader Valve
  • Hubs: Hubs: 36H Disc Nutted Front, Nutted Rear
  • Tires: 27.5 x 2.1 Puncture Resistant, Reflective Sidewalls

Ebike System

  • Motor: 500w, 48v
  • Throttle: Throttle on demand
  • Display: LCD Smart "Easy Read"
  • Battery: 48V, 12.8Ah (614Wh), LG Cell, UL 2849 Compliant
  • Sensors: Torque Sensor
  • Charger: 48V, 3 Amp Fast Charger
  • Lights: Optional

Brakes

  • Brakes: Hydraulic

Drivetrain

  • Bottom Bracket: Square Taper, Sealed, Torque Sensor
  • Pedals: 9/16" Alloy Platform
  • Crankset: 170mm w/ 48 T
  • Rear Derailleur: Shimano 8 speed
  • Shift Lever: 8 Speed Trigger
  • Chain: 122 Link, 8 Speed
  • Cassette: 12-32T, 8 Speed

Cockpit

  • Saddle: Aventon Saddle
  • Seatpost: Forged Alloy, 30.9mm 2-Bolt Clamp
  • Stem: Threadless, 31.8mm, 90mm
  • Seat Clamp: 34.9mm Quick Release
  • Handlebars: Aluminum 31.8mm, Sweptback
  • Headset: Sealed Bearing Headset
  • Grips: Ergonomic Comfort

Miscellaneous

  • Suspension: None

What's in the box?

Included Accessories

  • Kickstand: Included, rear mount
  • Rear Rack: Optional
  • Fenders: Optional
The Aventon Pace 500.3 is a comfortable and powerful electric cruiser bike ideal for leisure rides. It features a 500W motor offering speeds up to 28 mph and a range of up to 60 miles on a single charge. The upright riding position, swept-back handlebars, and cushioned saddle ensure a relaxing ride, while the hydraulic disc brakes provide confident stopping power. For added safety and convenience, the Aventon Pace 500.3 comes equipped with integrated turn signals and lights. Users praise its ease of assembly, comfort, quality build, and attractive design.

Aventon

View full details

Size Guide

  • Frame Size: Regular / Large

    • Top Tube Length (mm): 625 / 662
    • Reach (mm): 350 / 383
    • Head Tube Length (mm): 215 / 225
    • Standover Height (mm): 733 / 770
    • Wheelbase (mm): 1094 / 1131
    • Min Saddle Height (mm): 760 / 860
    • Max Saddle Height (mm): 940 / 1000
