Aventon Sinch.2

General Info

• Model: Aventon Sinch.2 Ebike
• Ideal Use: All-Terrain
• Folding: Yes
• Rider Height: 4'11" - 6'2"
• Dimensions (Unfolded): 67” l x 23.25” w x 46” h

Performance

• Speed: 20 MPH
• Pedal Assist: 4 Levels
• Range: Up to 55 miles
• Weight: 68 lbs
• Total Weight Limit: 300 lbs

Frameset

• Frame: Single-Butted Aluminum Alloy
• Frame Style: Step-Through
• Fork: RST GUIDE-ML-20 45mm travel, with lockout

Wheelset

• Rim: Aluminum 36h Front & Rear
• Spokes: Black Stainless 13G Front / 12G Rear
• Tubes: Butyl Rubber, Schrader Valve
• Hubs: Hubs: 36H Disc Nutted Front, Nutted Rear
• Tires: 20 x 4

Ebike System

• Motor: 750w (peak), 500w (sustained), 48v
• Throttle: Throttle on demand
• Display: LCD Smart "Easy Read"
• Battery: 48V, 14Ah (672Wh) LG Cell, UL 2849 Compliant
• Sensors: Torque Sensor
• Charger: 48V, 3 Amp Fast Charger
• Lights: Front and rear lights integrated

Brakes

• Brakes: Mechanical

Drivetrain

• Bottom Bracket: Square Taper, Sealed, Torque Sensor
• Pedals: 3.x 3.5" Folding Platform
• Crankset: 170mm w/ 52 T
• Rear Derailleur: Aventon 8 speed
• Shift Lever: 8 Speed Trigger
• Chain: 114 Link, 8 Speed
• Cassette: 12-32T, 8 Speed

Cockpit

• Saddle: Aventon by Velo
• Seatpost: 30.9mm 1-Bolt Clamp
• Stem: Threadless, 31.8mm, 90mm
• Seat Clamp: 34.9mm Quick Release
• Handlebars: Aluminum 31.8mm, 650mm
• Headset: Sealed Bearing Headset
• Grips: Standard Sealed Grip

Miscellaneous

• Suspension: Front

Included Accessories

• Kickstand: Included, center mount
• Fenders: Included
• Rear Rack: Included
• Rear Rack Weight Limit: 55 lbs
