Bandit Pacer High-Step
Bandit Pacer High-Step
Couldn't load pickup availability
Technical Specifications
Technical Specifications
Range
Battery (wH)
696 wH Battery
Charging Time
6 Hrs
Top Speed
28+ MPH
Charger
ST 48V 2Amp
Charging Time
6 Hrs
Motor Power (W)
500W 65N.M Torque
Controller (V, W)
48V 500W 16A
Throttle Style
Half twist throttle
Display Type
Horizontal LCD Smart Color Display
Pedal Assist
6 Levels
USB Ports
YES
Wiring
Water resistant connectors and wiring harness
Components
Frame
6061 Aluminum
Fork
Rigid Steel Fork for 26'' Tire.
Handlebar
6061 Alloy Handlebar
Stem
90 mm length, 0 - 90º rise
Grips
Velo Vinyl Leather Grips
Bell
Zoom Integrated Bell
Rims
26'' 36 Hole
Tire Hub
Loose Ball 24H 28H 32H Hub
Tire Spokes
12 Gauge, Stainless Steel
Tires
26'' x 2.35'' Puncture Resistant Tire
Fenders
Full coverage front and rear fenders with hardware included
Brake Levers
Aluminum alloy levers with motor cutoff switch
Brake Calipers
Hydraulic Calipers
Brake Rotors
180 mm front and rear
Brake Pad Materials
Metallic
Crank Set
44T, 170 mm forged alloy, dual-sided aluminum crankset
Freewheel
7 Speed Freewheel 14-28T
Chain
KMC Z7
Gearing
1 x 7 Speed
Shifter
7 Speed Shimano Right Shift Lever
Derailleur
7 Speed Shimano Tourney
Saddle
Velo Plush Bicycle Seat
Seatpost Dimensions
31.6 mm x 400mm
Seatpost Clamp
Quick Release
Pedals
90 mm x 80 mm boron steel axle, Standard 9/16″ thread with reflectors
Kickstand
Heavy-duty aluminum with wide plastic foot
Front Light
Waterproof front LED headlight
Tail Light
Integrated rear lights
Rear Rack
YES
What's in the box?
What's in the box?
Included Accessories: Kickstand, Charger
Introducing the Bandit Pacer High-Step - equipped with a massive 696 wH battery and a top speed of 28+ MPH! With a 6-hour charging time, this e-bike is powered by a 500W motor and boasts a torque of 65N.M. The 48V 2Amp charger ensures quick charging, while the 6 levels of pedal assist make your ride effortless. Plus, the water-resistant connectors and wiring harness provide maximum durability. Feel confident riding on the 26'' puncture-resistant tires and navigate with ease using the 7-speed Shimano shifter and derailleur. With a sturdy aluminum frame and full coverage fenders, the Bandit Pacer is ready for any adventure. So, what are you waiting for? Upgrade your ride today and experience the power and efficiency of the Bandit Pacer High-Step.
Bandit
Share
Size Guide
-
- Weight: 67 lbs
- Reach: 19.7"
- Stack: 27.3"
- Max Seat Height: 41.3"
- Seat Tube Length: 16"
- Total Length: 71"
- Handlebar Height: 46.5"
- Standover Height: 26.4"
- Min Rider Height: 5'6"
- Max Rider Height: 6'9"
- Max Load Capacity: 440 lbs
