Hovsco HovRanger

MOTOR
970W (Peak) / 500W (Sustained), 48V Brushless Rear Hub Motor

BATTERY
Removable Internal Lithium-ion 48V, 15Ah (720Wh)

CHARGER
Included: 54.6V 3 Amp Fast Charger, 7 Hours Charging

DISPLAY
BC280 LCD Smart Easy Read Display with Backlight screen with app

CRANKSET
170mm w/ 42 T

CASSETTE
14-28T, 7 Speed Cassette

BOTTOM BRACKET
Square Taper, Sealed

BRAKES
Hydraulic Disc Brakes, 180mm Rotors

REAR DERAILLEUR
7 Speed

CHAIN
7 Speed

PEDALS
9/16" Alloy Platform

HANDLEBARS
Aluminum 31.8mm, 680mm

HEADSET
VP Sealed Bearing Headset

GRIPS
Ergonomic Comfort

SADDLE
Quality Ergonomic Saddle

SEATPOST
Forged Alloy, 30.4mm x 350mm, 2-Bolt Clamp

STEM
Threadless, 31.8mm, 7 Degree Rise

SEAT CLAMP
Quick Release

RIM
Double Wall Aluminum 36h Front & Rear

SPOKES
Black Stainless 12 Gauge

TUBES
Butyl Rubber, Schrader Valve

HUBS
36H Disc Thru-axle Front, Nutted Rear

TIRES
27.5 x 2.25" Ebike Rated Tires

FRAME
6061 Single-Butted Aluminum Alloy with Internal Battery

FORK
Suspension Fork with 75mm travel, with lockout

KICKSTAND
Included, Rear Mount

THROTTLE
Throttle on demand - Throttle from a complete stop

SPEED
Max 28 mph after unlocked

SENSORS
Torque Sensor

PEDAL ASSIST
5 Levels

RANGE
40-60 Miles Average

HOVSCO APP
Free Download in Apple App and Google Play Store

WEIGHT LIMIT
Maximum Payload Capacity: 300 lbs

WEIGHT
46.98 lbs (Not Including Battery)
55.8 lbs (Including Battery)

Item List

1. Electric Bike
2. Kickstand
3. Quick Release
4. Pedals
5. Charger
6. Derailleur Guard
7. Screws Kits
8. Allen Key Wrenches (4)
9. Wrenches (3)
10. Screwdrivers (2)
11. Owner's Manuals (2)
12. Front Wheel
13. Battery with Keys
14. Fender Set (Need to be purchased separately)
15. Rear Rack (Has been installed on bike)
16. Front Basket (Need to be purchased separately)
